LH520-20-24(20x80)-C3000
isolated Line lasermodule, green, 90°, 520nm, 20mW, 24V DC, 20x80mm, class 2
您是不是很惊讶我们的价格都是公开的、透明的? 而其他的供应商只是给您一个单独的报价? 我们的成本在坦诚相待的基础上也是透明的 所有的客户都是一视同仁的,您可以自由选择。
| 支: | 10 | 50 | 100 | 250 | 500 | 1000 |
| 折扣: | 10% | 15% | 20% | 25% | 30% | 35% |
| Warranty | 1Jahre |
| Beam Shape | 点 |
| Wavelength | 650nm (rot) |
| Optical Power | 0.3mW |
| Laser Class | 1 |
| Divergence | 1mrad |
| Beam Diameter | 3mm |
| Size of Laserdot | <4..6mm@5m |
| Operating Distance | 5m |
| Optics | acryl lense |
| Laser technology | Single Mode Diode |
| Size | |
| Material | aluminium |
| Focus | fixed (5.0m) |
| Output Aperture | 3mm |
| Potential of Housing | VDD(+) |
| Lifetime | >3000h |
| Operating Voltage | 3 - 4.5, typ 3V DC |
| Operating Current | 10 - 25, typ 15mA |
| Battery | LR44/AG13 alkaline battery, 1.5V |
| Housing Color | 黑色 |
| Operating Temperature | -20°C - 40°C |
| Storage Temperature | -40°C - 80°C |
| Weight | 27g |
