DD635-5-5(16X62)-DOE-USB
Numéro de commande: 70159929
Description du produit:
focusable isolated DOE lasermodule, red, 635nm, 5mW, 5V DC, 16x62mm, class 3R, USB
• adjustable focus
• DOE optic can be changed
• compact size
• glas lenses anti reflex coated
• Operating Voltage 5 V DC
Description du produit:
focusable isolated DOE lasermodule, red, 635nm, 5mW, 5V DC, 16x62mm, class 3R, USB
• adjustable focus
• DOE optic can be changed
• compact size
• glas lenses anti reflex coated
• Operating Voltage 5 V DC
Nous n'avons rien à cacher en matière de prix!
Vous vous étonnez de trouver ici des prix communiqués ouvertement ? Vous obtenez uniquement des offres individuelles auprès d'autres fournisseurs ? Notre évaluation des prix est également basée sur la transparence, la confiance et le même traitement de tous nos clients – et vous avez la possibilié de comparer!
| Unité: | 10 | 50 | 100 | 250 | 500 | 1000 |
| Réduction: | 10% | 15% | 20% | 25% | 30% | 35% |
- Spécification
Warranty 1Jahre Beam Shape DOE Wavelength 635nm
(rot)Optical Power 5mW Laser Class 3R Divergence 0.5mrad Operating Distance 50m Optics Lentille de verre revêtue d'AR Beam Mode TEM00 Laser technology Single Mode Diode Stability +/- 3% @ -10-50°C Size Material aluminium Cable length 300mm Wire type 18AWG, black, 3,6mm Focus réglable Output Aperture 5mm Potential of Housing isolé Lifetime >10000h Operating Voltage 4.7 - 5.3, typ 5V DC Operating Current 30 - 70, typ 51mA Housing Color noir Connector CON-USB-A Operating Temperature -20°C - 50°C Storage Temperature -40°C - 80°C Weight 30g Stripping of cable cover 50mm - Illustration et dessin technique
- Affectation des connecteurs
Dimensions:
noir GND Positif:
white 5V DC - Accessoires adaptés
LFNT-5
Référence: 70114683
Power Supply with stripped/tinned wires, Output: 5V DC, Input: 100-240V AC, 50-60Hz, Output Power: 3W max.
22.61 EUR- Downloads
