DE520-2.0-5(7x26)

Order number: 70141108

Product description:
Dot lasermodule, green, 520nm, 2.0mW, 5V DC, 7x26mm, class 3R

• compact size
• Laser Class 3R
• Operating Voltage 5 V DC

76,39
All prices in euros plus VAT at current rate and shipping costs.

We don't need to hide our prices!

Are you surprised that we communicate our prices so openly? Other suppliers only give you individual quotations? Our costing is also based on transparency, trust and treating all customers equally and this gives you the ability to compare!

Pcs:	10	50	100	250	500	1000
Discount:	10%	15%	20%	25%	30%	35%

Specification

Warranty	1Jahre
Beam Shape	Dot
Wavelength	520nm (grün)
Optical Power	2mW
Laser Class	3R
Divergence	0.6mrad
Beam Diameter	7mm
Operating Distance	10m
Optics	Glass lens AR coated
Laser technology	diode
Size
Material	Stainless Steel
Cable length	115mm
Wire type	26AWG, UL, isolated
Focus	collimated
Output Aperture	4.3mm
Potential of Housing	VDD(+)
Lifetime	>10000h
Operating Voltage	3 - 6, typ 5V DC
Operating Current	150mA
Housing Color	silver
Operating Temperature	-20°C - 60°C
Storage Temperature	-40°C - 80°C
Weight	3.8g
Power Supply	Power Supply with stripped/tinned wires, Output: 5V DC, Input: 100-240V AC, 50-60Hz, Output Power: 3W max.
Stripping of wire	3mm

Illustration and technical drawing
Connector pin assignment
Ground: black GND
Positive: red 5V DC
