DI650-2-3(4x10)-ADJ

Order number: 70152500

Product description:
Adjustable Dot laser, 650nm, 2mW, Focus adjustable, spot size <0.04mm@15.1mm, 3V DC, pcb at the end of the housing

• Focus adjustable
• spot size <0.04mm@15.1mm
• Housing size 4x10mm
• pcb at the end of the housing

83,11
All prices in euros plus VAT at current rate and shipping costs.

We don't need to hide our prices!

Are you surprised that we communicate our prices so openly? Other suppliers only give you individual quotations? Our costing is also based on transparency, trust and treating all customers equally and this gives you the ability to compare!

Pcs:	10	50	100	250	500	1000
Discount:	10%	15%	20%	25%	30%	35%

Specification

Warranty	1Jahre
Beam Shape	Dot
Wavelength	650nm (rot)
Optical Power	2mW
Laser Class	3R
Divergence	1.5mrad
Size of Laserdot	<0.04mm@15.1mm
Operating Distance	0.015m
Optics	Glass lens AR coated
Laser technology	Single Mode Diode
Size
Material	Bronze
Cable length	120mm
Wire type	28AWG, Typ 1061, UL1061
Focus	adjustable
Potential of Housing	VDD(+)
Lifetime	>5000h
Operating Voltage	2.8 - 3.3, typ 3V DC
Operating Current	7 - 30, typ 15mA
Housing Color	black
Operating Temperature	-20°C - 50°C
Storage Temperature	-40°C - 80°C
Weight	3g
Power Supply	Power Supply with stripped/tinned wires, Output: 3.3V DC, Input: 100-240V AC, 50-60Hz, Output Power: 3.3W max.
PCB	Ja
Stripping of wire	5mm

Illustration and technical drawing
Connector pin assignment
Ground: black GND
Positive: red 3V DC
