DG635-6-3(12x34)

Order number: 70101836

Product description:
focusable isolated Dot lasermodule, red, 635nm, 6mW, 3V DC, 12x34mm, class 3B

• Operating Voltage 3 V DC
• Laser Class 3B
• compact size
• adjustable focus
• isolated housing
DG635-6-3(12x34) - Hauptbild
DG635-6-3(12x34) - Rendergrafik
DG635-6-3(12x34) - Zeichnung
DG635-6-3(12x34) - Zeichnung Front
DG635-6-3(12x34) - Zeichnung isometrisch
Warnlabel 3B
71,34
All prices in euros plus VAT at current rate and shipping costs.

We don't need to hide our prices!

Are you surprised that we communicate our prices so openly? Other suppliers only give you individual quotations? Our costing is also based on transparency, trust and treating all customers equally and this gives you the ability to compare!

Pcs: 10501002505001000
Discount: 10%15%20%25%30%35%
  • Specification
  • Warranty1Jahre
    Beam ShapeDot
    Wavelength635nm
    (rot)
    Optical Power6mW
    Laser Class3B
    Divergence0.8mrad
    Size of Laserdotadjustable
    Operating Distance60m
    OpticsGlass lens AR coated
    Laser technologydiode
    Size
    MaterialBronze
    Cable length100mm
    Wire type26AWG, 0,14mm²
    Focusadjustable
    Output Aperture5mm
    Potential of Housinginsulated
    Lifetime>5000h
    Operating Voltage2.7 - 3.3, typ 3V DC
    Operating Current25 - 75, typ 50mA
    Operating Temperature-20°C - 50°C
    Storage Temperature-40°C - 80°C
    Weight16.5g
    Power SupplyPower Supply with stripped/tinned wires, Output: 3.3V DC, Input: 100-240V AC, 50-60Hz, Output Power: 3.3W max.
    • Illustration and technical drawing
    • DG635-6-3(12x34) - Hauptbild
      DG635-6-3(12x34) - Rendergrafik
      DG635-6-3(12x34) - Zeichnung
      DG635-6-3(12x34) - Zeichnung Front
      DG635-6-3(12x34) - Zeichnung isometrisch
      Warnlabel 3B
      Connector pin assignment
      Ground:Cable color Ground: blackblackGND
      Positive:Cable color Positive: redred3V DC
    • Matching accessories
    • AM1-1203SZAM1-1203SZ
      Order no.: 70114928
      DC DC Converter IN=12V OUT=3V 1 Watt (300 mA)
      16.72 EUR
