DI650-0.4-3(5x12)-C80
micro dot lasermodule, red, 650nm, 0.4mW, class 1, 5x12mm, 3V DC, cable length…
DBI650-1-24-FA(12X60)-F3400-M8
Número de pedido: 70190007
Descripción del producto:
Isolated point laser module, red, 650nm, 1mW, 24V DC, 12x60mm, Class 2, with M8 connector (42-00009)
• With M8 connector 42-00009 (3-pin)
Descripción del producto:
Isolated point laser module, red, 650nm, 1mW, 24V DC, 12x60mm, Class 2, with M8 connector (42-00009)
• With M8 connector 42-00009 (3-pin)
¡No hace falta que ocultemos nuestros precios!
¿Le sorprende que informemos de nuestros precios de manera tan clara? ¿Sólo recibe ofertas individuales de otros proveedores? Nuestro cálculo de costos se basa en la transparencia, la confianza y la igualdad de trato de todos nuestros clientes - ¡y así usted tiene la opción de comparar!
| Unidades: | 10 | 50 | 100 | 250 | 500 | 1000 |
| Descuento: | 10% | 15% | 20% | 25% | 30% | 35% |
- Características
Warranty 1Jahre Beam Shape Punto Wavelength 650nm
(rot)Optical Power 1mW Laser Class 2 Divergence 0.3mrad Size of Laserdot <1.25mm@3.4m Operating Distance 3.4m Optics Lente de cristal con recubrimiento AR Laser technology Single Mode Diode Size Material aluminium Cable length 500mm Wire type 22AWG, black, 3,6mm Focus fixed (3.4m) Output Aperture 5mm Potential of Housing aislado Lifetime >5000h Operating Voltage 23.5 - 25.5, typ 24V DC Operating Current 1 - 15, typ 5mA Housing Color negro Connector CON-M8-3POL Operating Temperature -20°C - 50°C Storage Temperature -40°C - 80°C Weight 10.5g - Imágenes y dibujo técnico
- Asignación de conectores
Dimensiones:
negro GND Stecker Pin Dimensiones: 3 Positivo:
rojo 24V DC Stecker Pin Positivo: 1 - Accesorios idóneos
LFNT-24-C
Pedido Nr.: 70115055
Power Supply, Output: 24V DC, Input: 100-240V AC, 50-60Hz, Output Power: 24W max.
SYS 1308-2424-W2E | 2,1 x 5,5 x 11 center positive
31.85 EUR- Downloads
